Rating Frequency RPM kWm kWe kVa
PRP 50 Hz 1500 107 156 195
PRP 50 Hz 1500 205 192 240
PRP 60 Hz 1800 183 168 210
PRP 60 Hz 1800 224 208 260

Engine

Model Injection Speed Control Cylinder Configuration Bore/stroke (mm) Displacement (l)
6 M16 Mechanical Electronic 6 inline 126×130 9.70

Alternator

– 50/60Hz Frequency, 4 Pole
– Insulation / Heating Class H/H
– Electronic voltage regulation
– Brushless excitation
– IP23 Protection, Marine impregnation
– Single bearing

Dimensions and dry weight (mm/kg)

A – Length B – Width C – Height Weight
2408 1224 1275 1868
